Virtual Private Cloud (VPC)

archi

Subnet​

  • Is a virtual firewall
  • ex: eu-west has 3 AZ => 3 subnets
  • By default, is private
  • A subnet is always assigned to one AZ

Internet Gateway​

  • Allows resources (e.g: EC2 instances) inside VPC to connect to internet
  • High available and scale horizontally
  • VPC can be only attatch to one Internet Gateway and vice-versa
  • IGT in their owen they do not allow access to internet they need to to associated to the Route Table
  • It's responsible for a Static Network Address Translation (translate private ip to public ip)

Route Table​

  • Determines where network traffic is directed in a VPC
  • A VPC can have multiple route tables
  • Each subnet must be associated with exactly one route table. If no association is made, the subnet uses the main route table
  • Controls how the VPC Router forwards traffic leaving a subnet

Security group​

  • We can add any allowing rules (open ports)
  • It's linked to instances
  • They are stateful
  • Default SG can't be deleted
  • You can assign up to five security groups to the instance
  • Can allow traffic from:
    • Range or individual IP address
    • Another security group
    • Rules are permissive
  • Can have
    • Up to 10000 SG per region (default 2500)
    • 60 inbound and outbound rules per SG
    • 16 SG per Elastic Network Interface

Network Access Control Lists (NACLs)​

  • Is an optional layer of security for VPC that acts as a firewall controlling traffic in and out of one or more subnets
  • It is used to block specific IP address or range of IP address
  • Can allow and deny rules
  • It can have multiple subnets but a subnet is only associated to only one NACLs
  • They are stateless
  • Default rule cannot be updated

VPC Peering​

  • Link VPCs together using private network
  • Allows you to connect 1 VPC with another via a direct network route using private IP address
  • Instances behave as they were in the same VPC
  • We can peer between different AWS account (cross-account) and different regions
  • Transitive peering is not supported
  • No overlapping CIDR address ranges
  • Data is encrypted

NAT Gateway​

  • Access internet from private subnet
  • One sense private subnet ==> internet
  • Redundant inside AZ
  • Start at 5 Gbps and scales currently to 45 Gbps (Bandwidth)
  • No need to patch
  • No associated to Security Group
  • Automatically assigned a public IP address
  • Access AWS services privately from private subnet, without public IP, IGW or NAT.
  • Two types
    • Interface endpoints
    • Gateways endpoints (Support connection to S3 and DynamoDB)
  • Doesn't need VPC Peering, public internet, NAT Gateway, Route Tables
  • Must be used with Network Load Balancer & ENI

VPC Flow logs​

  • Allow to capture IP traffic information in-and out of Network Interfaces within a VPC
  • Can be created for:
    • VPC
    • Subnets
    • Network Interface
  • Track the logs
  • Cannot be tagged as other resources
  • Contains source and destination IP addresses

Difference Security Group and NACLs​

  • Security groups are assigned to a specific resource, while NACLs are assigned to a subnet
  • Security groups do not allow explicit denies, while NACLs do
  • Security groups are stateful, while NACLs are stateless

Direct Connect (DX)​

  • Establish a dedicated network connection from on-premise to AWS
  • Two types
    • Dedicated connection ??
    • Hosted connection ??
  • Useful for high throughput workloads
  • Helpful when you need stable and reliable secure connection

Site-To-Site (VPN Connection)​

  • Utilizes IPSec to establish encrypted network connectivity between your intranet and Amazon VPC over the Internet
  • VPN Connections can be configured in minutes and are a good solution if you have an immediate need have low-to-modest bandwidth requirements, and can tolerate the inherent variability in Internet-based connectivity
  • Customer Gateways: Created on-premise side
  • Virtual Private Gateway: Created on AWS side

AWS Wavelength​

  • AWS service embeds AWS compute and storage services within 5G networks, providing mobile edge computing infrastructure for developing, deploying, and scaling ultra-low-latency applications

Bastion (Jumpbox)​

  • Get access via SSH to private subnet

Endpoints​

Interface Endpoints​

  • They are Elastic Network Interfaces (ENI) with private IP address
  • They serve as an entry point for traffic going to a supported service

Gateway Endpoints​

  • Is a target for a specific route in the route table
  • Supports only DynamoDB and S3

CloudHub​

  • Connect multiple sites
  • Low cost and easy to manage
  • It operates over public network, but all traffic between Customer Gateway and AWS VPN CloudHub is encrypted

Transit Gateway​

  • Connects VPCs and on-premise networks through a central hub (single gateway)
  • Scales elastically based on the volume of network traffic
  • Routing through a transit gateway operates at layer 3, where the packets are sent to a specific next-hop attachment, based on their destination IP addresses

Egress-only Internet Gateway​

  • Used for IPv8 only
  • Similar to a NAT Gateway but for IPv6
