Kerberos

  • It's a client/server based architecture

picture alt

  • Principal: an identity that needs to be verified

    • User Principal Names (UPN): similar to usernames in operating systems.
    • Service Principal Names (SPN): is the service that the user needs to access (database, server, ...).

  • Realm:

    • A realm in Kerberos refers to an authentication administrative domain.
    • Principals are assigned to specific realms in order to establish boundaries and simplify administration.

  • Key Distribution Center (KDC): contains all information about principals and realm. It consists of:

    • Kerberos database: it stores
      • UPN and SPN
      • To which realm principal belongs to
      • Encryption keys
      • Tickets validation duration
      • Expiration date
      • ...
    • Authentication Server (AS):
      • Delivers TGT (Ticket Granting Ticket)
      • Authenticates users
      • TGT is delivered if authentication is successful
    • Ticket Granting Server (TGS):
      • Validates TGT
      • Delivers TS (Ticket Service)

  • KeyTab: file that contains all keys related to specific service

Principal parts​

  • Primary
    • <shortname>@<REALM>
    • Example: bob@EXAMPLE.COM => bob belongs to realm EXAMPLE.COM
  • Instance
    • <shortname>/<instance>@<REALM>
    • Example: username/admin@EXAMPLE.COM
  • Service
    • <shortname>/<hostname>@<REALM>
    • Example: hdfs/node1.domain.com@EXAMPLE.COM => service hdfs in the node node1.domain.com

PS: naming is case-sensitive

Trust​

  • One way
  • bidirectional trust or full trust

Advantages​

  • Is Single sign on
  • Password do not travel in clear over the network
  • A centralized repository for all users and services credentials

Example: Access hdfs​

  1. Authenticate using kinit service
  2. Sends authentication to Authentication Server
  3. If OK: AS sends TGT to user and kinit will store TGT in a credential cache and user is Authenticated
  4. Now user wants to run command hdfs dfs -ls
    1. Hadoop will use TGT and reach Ticket Granting Server
    2. TGS will grant TS (Ticket Service) and client will cache TS
  5. Hadoop RPC will use TS to reach the Namenode
  6. Client and Namenode exchange Tickets (Client ticket prove client identity and Namenode determines the identification of Namenode)

Kerberos on Hadoop​

  1. Create KDC
  2. Create service principal for each service (HDFS, Yarn, ...)
  3. Create Encrypted Kerberos Keys (Keytabs) for each service
  4. Distribute keytab for service principals to each service on the cluster nodes
  5. Configure all services (HDFS, Yarn, Hive, ...) to rely on Kerberos

Installation​

Server Side​

1. Install Kerberos Admin Server: install the server and KDC

yum install krb5-workstation krb5-libs krb5-server

2. Configure Kerberos

  • Two configuration files

    • /etc/krb5.conf
    • /var/kerberos/krb5kdc/kdc.conf

  • Configure the realm

sudo vi /etc/krb5.conf

[realms]
 # realm name
 HADOOP.COM = {
  # the name of KDC
  kdc = server.hostname.com
  # The admin Server
  admin_server = server.hostname.com
 }
  • Configure KDC

vi /var/kerberos/krb5kdc/kdc.conf

4. Create KDC database

    kdb5_util create -r HADOOP.COM -s

5. Specify the admin principals and add admin principal

  • All users in realm */admin@HDPCLUSTER.COM will have admin access
  • kadmin.local utility used only on the krb server
vi /var/kerberos/krb5kdc/kadm5.acl
kadmin.local -q "addprinc root/admin"

6. Start kdc and the server

service krb5kdc start
service kadmin start

7. Test

# list if ticket is present in cache
klist

# get ticket
kinit username

# add principal
kadmin
addprinc username@REALM.COM

Client Side​

1.Install

yum install krb5-workstation krb5-libs krb5-auth-dialog
